• Designed for Australian Conditions

• Reliable Supply & Shorter Lead Times

• Quality You Can Trust

• Long-Term Support & Serviceability

• Sustainable Manufacturing

• Supports Local Jobs & Industry

• Customisation & Flexibility

• Designed to Last

Our architectural lighting solutions are designed for a wide range of applications including:

• Public spaces and parks

• Pathways and shared user paths

• Pedestrian bridges

• Streetscapes and urban environments

• Building facades

• Shelters and public infrastructure

• Landscape and feature lighting

• Coastal and environmentally sensitive locations

Yes. Many products can be customised to meet project-specific requirements, including:

• Beam distributions

• Colour temperatures

• Output levels

• Mounting arrangements

• Finishes and colours

• Control interfaces

• Bespoke accessories

Beam options vary by product and optic selection. Depending on the luminaire, narrow, medium, wide, asymmetric, wall wash, and custom optical distributions are available.

Yes. IES, LDT and other photometric files are available on our website for lighting design calculations and project modelling.

Yes. Many Planet Lighting products are specifically designed for harsh outdoor environments, including coastal and marine applications. Please contact our team to discuss the suitability of a specific product for your project.

Depends on the product. Standard options typically include:

• 1800K

• 2200K

• 2700K

• 3000K

• 3500K

• 4000K

• 5000K

• 6500K

Yes. Many Planet Lighting luminaires are designed with low-glare optics and zero-uplight distributions to minimise light spill and help reduce light pollution.

Absolutely. Our team can provide product selection advice, photometric support, specification assistance, and project-specific recommendations.

Depending on the product range, available control options may include:

• DALI

• Casambi

• 1–10V

• SwitchDIM

• Tunable White

• DMX

• Custom control solutions

Planet Lighting products are designed for long operational life, with many installations continuing to perform well after more than 10 years of service. Design life varies by product and application.

Planet Lighting Architectural Lighting Systems and Products are covered by a 5-year repair or replacement warranty. Extended warranties may be available for selected projects.

The warranty period on parts supplied for repair is 1-year.

Yes. As an Australian manufacturer, Planet Lighting supports repairability and long-term product maintenance through the availability of spare parts and service support.

Simply contact our team with your project details, drawings, or lighting requirements and we will recommend the most suitable solution for your application.

Datasheets, photometric files, installation instructions and other technical resources are available through the Planet Lighting website or by contacting our team directly.

The maximum cable run depends on several factors, including the total number and type of luminaires, cable construction (copper/Kevlar or copper only), cable sag, and installation configuration. As a general guide, a cable run of up to 100 metres is achievable.

Refer to the Catenary Calculator for project-specific calculations.

The maximum number of luminaires per run depends on the catenary length, cable type, loading, and electrical design. As a general guide, up to 60 luminaires can be connected per run.

Refer to the Catenary Calculator for the correct configuration.

Voltage drop requirements vary depending on the installation length, cable size, luminaire load, and system configuration. Refer to the Catenary Calculator to verify compliance with the recommended design parameters.

The maximum span between fixing points depends on the cable type, loading, sag, environmental conditions, and installation requirements. The catenary cable has a Safe Working Load (SWL) of 200 kgf (2,000 N).

Refer to the Catenary Calculator to determine the maximum permissible span and cable loading for your application.

LED Puck Air is only available in IP67.

The maximum number of LED Pucks that can be connected to a single driver depends on several factors, including cable length and conductor size. As a general guideline, a single driver can support up to 35 LED Pucks over a maximum cable run of 100 metres (from the driver to the last luminaire) using 0.5 mm² cable.

Please refer to the LED Puck Snap Wiring Guide for a range of typical wiring configurations and recommended installation options.

Our standard wiring configuration is series.

For larger installations where a greater number of luminaires is required without increasing the number of cable pairs, we also offer parallel and series-parallel wiring arrangements. These configurations should be developed in consultation with Planet Lighting, as cable lengths, voltage drop, driver loading, and project-specific requirements must be assessed to determine the most suitable solution.

There is no universal spacing rule that guarantees compliance, as the appropriate spacing depends on numerous project-specific factors, including:

• Applicable lighting standards and compliance requirements

• Pathway width

• Handrail height

• Single-sided or double-sided illumination

• Beam distribution

• Correlated Colour Temperature (CCT)

• Colour Rendering Index (CRI)

• Surface reflectance of surrounding materials

• Required horizontal and vertical illuminance

• Uniformity requirements

These parameters should be      evaluated through a lighting design and photometric assessment to determine compliant luminaire spacing.

Where a customer requests a preliminary spacing recommendation without a formal lighting design or compliance assessment, we typically suggest 1 metre centres as a practical starting point. This provides a balanced outcome between lighting performance and project cost, although final spacing should always be verified against the project's lighting requirements.

Recommended hole tolerance for LED Puck Snap installation: +0.1 mm / -0.0 mm.

The LED Puck Snap range is supplied with an IP67 rating as standard. An IP68 rating is available as an option. Please note that the Lens, Solo RGBW, and Solo Tunable White variants are only available with an IP68 rating from the rear only.

The IK rating remains unchanged unless the luminaire is fitted with borosilicate glass. In that case, the applicable IK rating may differ due to the characteristics of the borosilicate glass.

Please refer to the LED Puck Snap, LED Puck MegaPuck & LED Puck Air Maintenance Guide for detailed maintenance and replacement procedures.

• Parallel

• Series

• Series-Parallel

• 20 (700mA 24VDC)

• 40 (700mA 48VDC)

• 6 (700mA/8W)

• 8 (500mA/6W)

TCI MAXI JOLLY HV constant current LED driver set to 500mA or 700mA.

Available in 17 colours and a range of white options.

• 2700K

• 3000K

• 3500K

• 4000K

• Tunable White

• RGBW

IP67 / K10

Yes. LED Puck Snap and LED Puck MegaPuck can be configured for emergency lighting applications.
